ELEVATED WATER TANK & STEEL TOWER
An elevated water storage tank-also commonly known as an overhead water tank-is a water storage system installed at a height, typically supported by a steel or concrete tower. The elevated height allows the tank to generate natural water pressure through gravity, making it ideal for supplying water to homes, farms, factories, schools, or remote communities without relying on continuous electric pumping.
An elevated water tank system typically consists of two major components(One is water tank and one is the structure):
The Water Tank-Mounted at the top of the structure, the tank holds the water and can be made from various materials based on application needs:
The Support Structure (Steel Tower)-The tank is supported by either a steel tower or a concrete tower, which elevates the tank to the desired height and ensures structural stability. Steel towers are more commonly used due to flexibility and faster installation.
Types of Steel Tower | Advantages |
Hot-Dip Galvanized (HDG) Steel Tower | Long-lasting, rust-resistant, suitable for coastal or humid environments |
Painted Steel Tower | Cost-effective, suitable for dry inland regions, requires periodic maintenance |
Smart Design: Right Tank Size + Right Tower = Lowest Cost
We don't just design based on tank capacity - we also optimize the tank's length, width, and height, along with the tower's steel structure and materials, to ensure the most cost-effective and structurally sound solution for each project.
By carefully adjusting the tank dimensions and tower specifications, we help clients reduce material costs, simplify installation, and achieve the lowest possible total cost for their elevated water tank systems.
Steel water towers are called steel water framing which are tall structures made primarily from durable steel. They elevate large water storage tanks high above the ground, ensuring a consistent water supply through gravity-fed pressure. They are commonly used in residential, commercial, industrial, and agricultural settings where water needs to be stored and delivered reliably.
Specifications
Steel Tower Technical Specifications for Elevated Steel &GRP Water Tanks
Constructed with Q355B/Q235B welded/hot-rolled H-section steel (main frame) and angle steel (bracing), this bolted tower withstands extreme winds (100-300 km/s) and offers a 50-year lifespan. Ideal for telecom, power transmission, and renewable energy, its durable, corrosion-resistant design ensures reliability in harsh environments.
Item | Specification |
Main Steel Frame - Column/Beam | Q355B/Q235B Welded/ Hot rolled H Section Steel |
Secondary Frame - Bracing | Angle Steel |
Connection | Bolted |
Wind Speed | 100km/s to 300km/s |
Structure Usage | Up to 50 years |
Product Parameters
• H section steel column, beam, and angle steel support
• Access ladder with safety cage
• Option of having a walkway around the tank
• Design certificate from registered professional engineer
• Surface finish: galvanized or painted
• The tower height can be 3m, 6m, 10m, 12m, 15m etc. At present, we have made the highest tower 28m.
• All the steel parts are prefabricated in factory, just assemble together with bolts&nuts.
Advantages
1.Strength and Durability | Steel is renowned for its high tensile strength, making it ideal for constructing towers that need to withstand significant pressure. Properly maintained steel water towers can last for decades, even in harsh weather conditions. |
2-Quick Installation | Steel water towers are often prefabricated offsite, which significantly reduces construction time. Once the components are ready, the tower can be assembled and installed quickly, minimizing downtime. |
3-Design Flexibility | Steel allows for various design configurations, including cylindrical and spherical tanks, to meet specific capacity and aesthetic requirements. This flexibility makes steel towers suitable for both functional and decorative purposes. |
4-Ease of Maintenance | Steel water towers are relatively easy to inspect and repair. Protective coatings and regular maintenance can manage issues such as corrosion, ensuring a long lifespan. |
5-Recyclability | A steel water tower can be dismantled and recycled at the end of its life, making it an environmentally friendly option. |
